100% electricity

Programmable logic relays

Programmable logic relays

, LOVATO Electric system of modular components, has been still more enhanced with the introduction of a programmable logic relay, compact in size yet with excellent performance, suitable for the control and supervision of low and medium complexity automatisms.

Due to the multiplicity of functions, efficiently be used in diverse fields of industrial, service and residential applications.

Packaging machines, industrial dishwashers, lighting installations, irrigation systems, garbage disposal machinery, door and gate controls are just a few examples of where can be used.

Small Smart Simple

xpan a e Versatile

1 1 2 3 4 5 6 7 8 9 A B C

Programming

1

I/O STATUS

Value of analog inputs

1 2 3 4 5 6 7 8 9 A B C

At any time and with extreme simplicity, can be set up and reprogrammed to satisfy new requirements and improve the op- eration of a system. Programming is simple and intuitive and can be done directly on the relay keypad or by personal computer, connected by LRX C00 interface and using the relative LRX SW software.

A 5 = 5 . 3 5 A 6 = 0 . 1 0 A 7 = 2 . 7 0 A 8 = 8 . 3 2

I/O STATUS DATA

Memory, timer, counter, RTC and analog comparator state

Expansion inputs state

KEY ESC

TIME

Base unit inputs state

KEY

PLC STATUS

KEY

I D S E T 0 1 R E M O T E I \ O N B A C K L I G H T x M K E E P√ I \ O N U M B E R : 0 I \ O A L A R M :√ C K E E P x

2

3

LADDER1 FBD2 RUN3 CLEAR PROG.4 WRITE5 READ6

SET7 RTC SET8 ANALOG SET9 PASSWORD10 LANGUAGE11 INITIAL12

M E N U

When using aPersonal Computercommon language(PC), two logics are available for programming: Function Block Diagram (FBD) and LADDER (contact scheme). Using the Simulator option, the user can control the exactness of the implemented program in off-line simulation, directly on the PC, before the on-line testing and the system set-up.

Value of analog inputs

I N I T I A L

1 0 . 0 0

P R O G .

T 1

5

4

> Y E S N O

C L E A R

Analogs STATUS 1

-

D E F

A 1 = G A I N : 0 1 0 O F F S E T : + 0 0 A 2 = G A I N : 0 1 0 O F F S E T : + 0 0 A 3 = G A I N : 0 1 0 O F F S E T : + 0 0 A 4 = G A I N : 0 1 0 O F F S E T : + 0 0

x

1 2 3 4 5 6 7 8 9 A B C

R U N

11

E N G L I S H F R A N C A I S E S P A N O L I T A L I A N O D E U T C H P O R T U G U E S C H I N E S E

M O 1 0 : 3 1

1 9 . 0 9 . 0 5

10

Programmingthe keypadis quite simple and straight forward, without particular programming knowledge. There are 8 function keys on the relay front, dedicated to on-board adjustment, control and supervision of digital input and output status, analog input values, time and date entry and the operation status of the relay itself. Programming sequences are shown on a backlit 4-line 12-charac- ter display.

1

1

I 1 - M 1 - - - - ( Q 1 I 2 - Q 1 - m 1 - - - - ( T 1

R T C S E T V 1 . 4 0 5 . 0 9 . 1 9 M O 1 3 : 4 3

8

P A S S W O R D 0 0 0 0

9

R U N

W R I T E

> Y E S N O

> Y E S N O

P R O G .

> Y E S N O

> L A D D E R F B D

6

A 1 = 1 . 2 5 A 2 = 0 . 0 0 A 3 = 2 . 4 0 A 4 = 6 . 5 9

R E A D

Expansion outputs state Date

Base unit outputs state Date and time LRD state

12

7

Applications

Residential and home automation • Lighting • Alarm and fire systems • Garden irrigation and pool filling systems • Heating and air-conditioning control • Shutter and roller shutter control.

Main features

Industrial buildings

• Automatic door, gate or window opening and closing • Boiler and heating control • Ventilation and air conditioning • Alarm and fire systems • Lighting.

• Available power supply: 24VDC or 24VAC or 100-240VAC units • 10, 12 and 20 input-output base units • Expansion models with 4 inputs and 4 outputs • Maximum configuration: 44 inputs/outputs • 8A Ith current relay outputs for AC and DC versions • 0.3A 24VDC transistor outputs for DC version • 0-10V analog inputs for DC version • Standard-supplied Real Time Clock (RTC) • RS232 serial interface port for PC or program back-up memory connection • 4-line 12-character display with backlight • Programming language logics: Ladder (200 lines maximum; 5-20ms sampling time) or FBD (99 blocks maximum; 2-10ms sampling time) • On-board programming languages: Italian, English, Spanish, French, German, Portuguese and Chinese • PC programming languages: Italian, English and Spanish • Modular housing with 35mm DIN rail mount or screw fixing on mounting plate.

Small relay Exceptional performance

Industrial machinery

• Compressor, motor, pump control • Industrial washing machines • Mixers and blenders • Garbage shedders and compactors • Car washing systems • Bending machines • Welding machines.

Cold storage and refrigeration • Timers • Temperature control • Humidity and ventilation control • Compressor control.

Accessories and communication module

• The LRX 1V3 D024 power supply produces a direct-current voltage to power the base and expansion modules in circumstances when 24VDC is not available in the application. The power supply can also be used to power eventual 24VDC auxiliary circuits.

combines the facility of numer- ous traditional devices, such as con- trols relays, timers, counters, hour meters and so on. The advantages are many: cost reduc-

Applications

Conveying and transfer systems • Conveyor belts • Stop and go controls • Automatic programmed stopping • Luggage belts • Storage and car silos.

tion of materials and installation time, space reduction, easy reprogramming when needed, and function adjustment of the system for relay adaptation to new installation requirements.

Level and pressure control • Automatic valve opening and closing control • Level controls • Pressure controls • Pump change • Storage silo and tank filling and draining.

• The LRX M00 backup memory consents to save the user’s program and to simply and quickly transfer it to other base modules. ® • The LRE P00 expansion implements communications using Modbus protocol.

Greenhouses

• Lighting • Temperature control • Humidity control • Irrigation • Sprinkling systems.

is available for 24VDC or 24VAC or 100-240VAC power supply and with 10 to 44 inputs and outputs.

Expansion modules

Lifting mechanisms

• Bridge crane control • Roadway barriers and gates • Automatic car garages • Platforms • Hoists and lifts.

can be easily adapted to every type of need. The number of inputs and outputs of the base relay unit can be directly increased by using the expansion modules. Supplied in three base units with 10, 12 or 20 inputs/outputs, can be expanded mounting up to 3 expansion modules, to obtain a maximum configuration of 44 inputs/outputs.

LRD10… LRD12…

LRD10…

LRD12…

LRD20…

Expansions

LRD20…

+ LRE08 + LRE08 + LRE08 + LRE08 + LRE08 + LRE08

+ LRE08 + LRE08 + LRE08 + LRE08 + LRE08 + LRE08

+ LRE08 + LRE08 + LRE08 + LRE08 + LRE08 + LRE08

LRE08…

Inputs/Outputs 10 (6 Inputs + 4 Outputs) 18 (10 Inputs + 8 Outputs) 26 (14 Inputs + 12 Outputs) 34 (18 Inputs + 16 Outputs) 12 (8 Inputs + 4 Outputs) 20 (12 Inputs + 8 Outputs) 28 (16 Inputs + 12 Outputs) 36 (20 Inputs + 16 Outputs) 20 (12 Inputs + 8 Outputs) 28 (16 Inputs + 12 Outputs) 36 (20 Inputs + 16 Outputs) 44 (24 Inputs + 20 Outputs)

How to order

Order code Power supply INPUTS Digital Digital/Analog (0-10VDC)❶ Total n° n° Base relay unit LRD12R D02424VDC 6 2 LRD12T D02424VDC 6 2 LRD20R D024424VDC 8 LRD20T D024424VDC 8 LRD12R A024024VAC 8 LRD20R A024024VAC 12 LRD10R A240100-240VAC 6 0 LRD20R A2400100-240VAC 12 Expansion and communication modules LRE08R D024024VDC 4 LRE08T D02424VDC 4 0 LRE08R A02424VAC 4 0 LRE08R A2400100-240VAC 4 ® LRE P00communication unitModbus protocol Accessories LRX M00Program backup memory LRX C00PC-LRD connecting cable, 1.5m long LRX SWProgramming and supervision software (cd-rom) LRX 1V3 D024Power supply unit, 100-240VAC/24VDC, 1.3A LRX D00User’s manual Italian edition (paper) LRX D01User’s manual English edition (paper) LRX D02User’s manual Spanish edition (paper) Starter kits LRDKIT 12R D024LRD starter kit complete with LRD12R D024 relay, LRX SW software and LRX C00 cable LRDKIT 12R A024LRD starter kit complete with LRD12R A024 relay, LRX SW software and LRX C00 cable LRDKIT 10R A240LRD starter kit complete with LRD10R A240 relay, LRX SW software and LRX C00 cable

Technical characteristics

Power supply Rated utilisation voltage Ue (Frequency range) Operating limits Digital inputs Rated voltage State 0 Input voltage State 1 0 to 1 Delay time 1 to 0 Analog inputs for 24VDC version only Input signal range Display resolution Conversion Current consumption at 10VDC Input impedance Admissible overload Maximum cable length Digital outputs Type of output / Rated current Ith Applied voltage Ambient conditions Operating / Storage temperature Relative humidity Maximum pollution degree Housing Version Type of terminal Conductor section Connections Tightening torque Maximum cable length LRD10… / LRD12… Dimensions (wxhxd) LRD20… Expansions LRE… Degree of protection Certfications and compliance

❶ Digital inputs can be used as analog inputs.

LRD…D024 24VDC 20.4-28.8VDC

24VDC < 5VDC / < 0.625mA > 15VDC / > 1.875mA 3-5ms 3-5ms

0-10V 0.01V 10bit < 0.17mA < 1kΩ 28VDC ≤30m of screened type LRD…R… / LRE08R… Relay / 8A 12-240VAC / 12-125VDC

LRD…A024 24VAC -

24VAC ❷ ❷ ❷ ❷

- - - - - - -

n°

4 4 8 8 4 8 4 8

4 4 4 4

Digital OUTPUTS Type

LRD…A240 100-240VAC (50-60Hz) 85-264VAC

Relay Transistor Relay Transistor Relay Relay Relay Relay

Relay Transistor Relay Relay

RTC

Yes Yes Yes Yes Yes Yes Yes Yes

No No No No

110-220VAC < 40VAC / < 0.28mA (LRD10R A240) < 0.15mA (LRD20R A240) > 79VAC / > 0.41mA 45-50ms (Ue=100VAC) – 18-22ms (Ue=240VAC) 45-50ms (Ue=100VAC) – 85-90ms (Ue=240VAC)

- - - - - - - LRD…T… / LRE08T… Transistor / 0.3A 24VDC 21.6-26.4VDC

-20…+55°C / -40…+70°C 20-90%, without condensation 2

Modular for mounting on 35mm DIN rail (IEC/EN 60715) or M4x15mm screw fixing Screw 2 0.75-3.5mm / 12 AWG 0.4-0.6Nm/0.3-0.4lbft ≤100m 72x106x57.3mm 126x106x57.3mm 38x106x57.3mm IP20

Certfications obtained: cULus; compliant with standards: IEC/EN 61131-2 Contact our Customer Service (Tel. [phone]) for details. ❷
